Proximity Sensor Failure After Screen Replacement

A frequent frustrating complaint for repair shops: after finishing a screen replacement, the proximity sensor stops working. The screen stays lit during phone calls instead of dimming, leading to accidental cheek taps, mis‑dialing and unwanted screen inputs.

Three main root causes for this fault:

1.Sensor misalignment: The new screen frame covers or shifts the proximity sensor cutout. Minor positional offset will break sensor detection.

2.Dust, glue or residual debris: Adhesive overflow, dust particles stuck on the sensor window block infrared signals. This often happens when installing screens without pre‑cleaning.

3.Incompatible or low‑grade replacement screen: Some aftermarket screens have poorly‑positioned cutouts. Low‑quality assemblies do not match original sensor geometry.

Step‑by‑step troubleshooting for technicians:

1.Power off the device, remove the screen assembly and carefully clean the proximity sensor area of dust and residual glue.

2.Re‑install the screen, double‑check that the sensor cutout perfectly aligns with the phone’s internal sensor module.

3.Avoid squeezing excessive adhesive over the sensor zone during bonding.

4.Test with another qualified screen module if misalignment comes from defective screen hardware.

Skipping pre‑installation cleaning and alignment checks will bring unnecessary returns. Choosing well‑fitting wholesale‑grade screen parts lowers this type of post‑repair failure.
